Multilayer Metal-Mesh Sand Control Screen with Perforated Base Pipe and Outer Shroud for Oil Gas Wells

Name: Multilayer MetalMesh Sand Control Screen with Perforated Base Pipe and Outer Shroud for Oil Gas Wells
Brand: OASIS
Price: 1 USD

Buy cheap Multilayer Metal-Mesh Sand Control Screen with Perforated Base Pipe and Outer Shroud for Oil Gas Wells product

Brand Name : OASIS

Model Number : OASIS-2025-03-20

Certification : ISO9001:2015 ISO14001:2015

Place of Origin : CHINA

MOQ : 10 Meter/Meters

Price : Negotiation

Payment Terms : L/C, T/T

Supply Ability : 6000 Meter/Meters per Month

Delivery Time : Within 35 days

Packaging Details : Wooden cases or pallet or bundle or container or according to clients' requirements

Filter Name : Profile Wire Sand Control Screen

Compliance : API, ISO certified

Corrosionresistance : High

Hole Shape : Round

Application : Oil & Gas Wells, Water Wells

Screen Type : Wire Wrapped, Perforated

Customization : Available upon request

Packing : As your request

Contact Now

Product Description

Engineered for Reliability and High Performance in Harsh Environments

Premium sand control well screens are specifically engineered to provide outstanding mechanical strength and precise filtration control in challenging oil and gas well operations. Built with a multi-layer design, Sand control well screens comprise four concentric layers: starting from the innermost component, these are the perforated base pipe, the intermediate support and drainage layer, the primary filter media (metal mesh or metal wool), and the outermost protective jacket made of stainless steel.these screens deliver superior sand retention, uniform flow distribution, and long-lasting durability under extreme downhole conditions.

Key Features

Robust Multi-Layer Construction: Sand control well screens combine drainage and filtration layers to prevent clogging and ensure stable performance.
Customizable Filtration: These screens are available in Dutch weave or square weave patterns with pore sizes ranging from 60 to 250 microns.
Corrosion-Resistant Materials: Sand control well screens utilize stainless steel (304L, 316L) and API-grade carbon steel options for enhanced service life.
Optimized Flow Design: The screens prevent channeling and maintain consistent fluid dynamics for improved well productivity.

Product Specifications

Base Pipe OD (in)	Coupling OD (in)	Weight (lb/ft)	ID (in)	Perforation Dia (in)	Flow Area (in²/ft)	Screen Weight (lb/ft)	Screen OD (in)
2.375	2.875	4.60	1.995	0.375	5.299	12.40	3.260
2.875	3.500	6.40	2.441	0.375	5.299	15.60	3.76
3.500	4.250	9.20	2.867	0.375	6.624	20.80	4.380
4.000	4.750	11.60	3.428	0.375	7.949	24.40	4.880
4.500	5.000	13.50	3.920	0.375	9.274	29.50	5.380
5.000	5.563	15.00	4.408	0.375	9.274	30.00	5.880
5.500	6.050	17.00	4.892	0.375	10.598	33.50	6.380
6.625	7.390	24.00	5.921	0.375	11.923	44.00	7.510
7.000	7.657	23.00	6.366	0.375	13.248	45.00	7.880

Technical Highlights

Base Pipe: Sand control well screens feature API-grade carbon steel or stainless steel (ASTM/ASME compliant)
Filtration Media: These screens incorporate 304/316L stainless steel, Dutch or Square weave
Outer Shroud: The screens feature laser-cut slots or precision perforations per API/ISO standards
Customization: Sand control well screens offer tailored dimensions, layer configurations, and materials to meet specific project needs

More Details

Multilayer Metal-Mesh Sand Control Screen with Perforated Base Pipe and Outer Shroud for Oil Gas Wells

Inspection

Multilayer Metal-Mesh Sand Control Screen with Perforated Base Pipe and Outer Shroud for Oil Gas Wells

Related Products

Multilayer Metal-Mesh Sand Control Screen with Perforated Base Pipe and Outer Shroud for Oil Gas Wells

Wedge Wire Screen

Why Choose OASIS Screens?

With over 12 years of expertise in sand control solutions, our sand control well screens offer:

Advanced R&D and high-quality manufacturing
Customized designs for varying well conditions
Strict quality control and final inspection before shipment
Global shipping and flexible payment options (T/T, L/C)

For more information or to request a custom solution, contact our technical team today.
